Ejector forward will be counted one time and ejector backward will also be counted one
time. If count 2 is odd number, ejector will stay at forward position, and it will retract
automatically before next mold close action.
If EJECT ON FLY function is on
，
ejector counter 1 IS NOT used
，
use ejector counter 2
ONLY.
Ｅ
DELAY
：
The delay time for ejector advance and retract
，
it is to be used when machine
runs with robot
，
delay some time to let robot move into mold area to catch parts.
Forward delay time is only used for one time
，
while backward delay is used in every
backward movement.
Ｆ
EJECT RET. MID. PT.
：
It is the retracted position for ejector forward 2 sequences. ejector
advances to forward position 2
，
then ejector retracts to EJECT RET. MID. PT.
，
3 ejector
advances to the FWD. END
，
4 ejector retracts to RET. END.
Ｇ
ROBOT CYCLE TIME.
：
Total cycle time of robot sequences
，
timer start count when
IO.196 is on (enable robot move in mold area)
，
timer stops when IO.222 is on (enable
mold close).
BILL 2
11
4
2
