Injection Molding Machine Chapter 4
V3.0
4-16
time is finished，ejector process starts no matter where mold position is at open end
position or not.
I， J， K is an special option feature.
Ｉ IN MOLD CUT：When set on，after charge，IN MOLD CUT DELAY starts timing，when
time’s up，ejector advances to ejector advance position 1，then retracts to RET. END
position，then do charging，cooling，mold open ……
Ｊ IN MOLD CUT DELAY：delay time after injection for ejector advance.
Ｋ CUT EJ.BACK DELAY：delay time for ejector retracts.
Remark: this function MUST work with special designed mold.
