Model Baja 150
Model Number CS150T-B
Length 75 inches
Width 23 inches
Height 48 inches
Dry Weight (No fuel) 249 lbs
Max. Load 330 lbs
Most Economical Speed 30 mph
Noise 80dB(A)
Engine Type Air Cooled - 4 Stroke
Cylinder Arrangement Single Cylinder
Displacement 150cc
Ignition Type CDI
Transmission CVT
Front Brake Disc
Rear Brake Drum
Tire Size (Front) 130/60 x13
Tire Size (Rear) 130/60x13
Tire Pressure (Front) 29psi
Tire Pressure (Rear) 33psi
Rated Power 9.5Hp/7000 RPM
Max. Torque 10.4/5500RPM
D: SPECIFICATIONS
Idle RPM 1500
Exhaust Vale Gap (Cold) 0.10 mm
Spark Plug Type Autolight 4194
Battery Type 12V 8Ah
Headlight (Hi / Lo Beam) 35 W / 35 W
Front Running Light 3 W
Brake / Tail Light 21 W / 5 W
Turn Signal Lights 10 W
Turn Signal Indicators 3 W
Instrument Illumination 3 W
Fuses 15 Amps
Fuel Type 90 Octane
Fuel Capacity 5.5 L / 1.45 gals
Lubricating Oil SAE 10 W30
