700 SERIES
MIXER/AMPLIFIERS
Tel:800-733-7088
Fax:800-733-9766
www.toaelectronics.com
S PECIFICATIONS
Type Nine channel mixer/amplifier
Output Power A-706: 60 W RMS, A-712: 120 W RMS, A-724: 240 W RMS
Frequency Response 50 - 20k Hz (±3 dB)
Total Harmonic 0.5% at 1k Hz, rated output
Distortion
Inputs Input 1 - 6: Mic -70 to -50 dBV, 600 Ω/Line -10 dBV, 600 Ω
Input 1: transformer-balanced, Phoenix 3P terminal
Input 2-6: electronically-balanced, Phoenix 3P terminal
Input 7 - 8: Line -20 dBV, 10k Ω, unbalanced RCA pin jack (stereo-sum)
Module: Specifications dependent on module type
Power IN: 0 dBV, 10k Ω, unbalanced, RCA pin jack
Outputs Speaker OUT: 70.7 V line, 25 V line, and 4 - 16 Ω, Phoenix 4P terminal
Minimum Impedance:
70.7 V line: 83 Ω (A-706), 42 Ω (A-712), 21 Ω (A-724)
25 V line: 10 Ω (A-706), 5.2 Ω (A-712), 2.6 Ω (A-724)
Preamp OUT: 0 dBV, 600 Ω, unbalanced, RCA pin jack
Rec OUT: 0 dBV, 600 Ω, unbalanced, RCA pin jack
Output Regulation Less than 2 dB, no load to full load
Phantom Power 23 VDC, switchable, Inputs 1 - 6
Module Slot Card edge connector connects to audio input and output points of TOA 900 Series modules. Use of Mute-type
modules is not required in 700 Series models.
Dynamic Range Input 1 - 6: >70 dB
Input 7 - 8, Module: >80 dB
(Band Pass: 20 Hz - 20k Hz, with Tone Controls centered)
Tone Control Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10k Hz
Control Input Remote Volume: 10k Ω linear-taper potentiometer, Phoenix terminal
Power Remote: No-voltage make contact input
Open voltage: 28 VDC (when unit power is OFF)
Short-circuit: Under 10 mA, Phoenix terminal
Mute Control: No-voltage make contact input
Open voltage: 28 VDC (when unit power is OFF)
Short-circuit: Under 10 mA, Phoenix terminal
Indicator 5-point LED output level meter, Power indicator LED
Power Source 120 VAC, 60 Hz
Power Consumption A-706: 68 W, A-712: 110 W, A-724: 215 W
(Based on UL/CSA standard)
Operating Temperature 14
º
F to 104
º
F (-10
º
C to + 40
º
C)
Finish Panel: ABS resin, black, hair line
Case: Steel plate, black
Dimensions (W x H x D) 16.8” x 4.3” x 14.68” (420 x 107.7 x 367 mm)
Weight A-706: 20.55 lbs (9.3 kg), A-712: 27.85 lbs (12.6 kg), A-724: 29.84 lbs (13.5 kg)
Accessories
(included) 4 x Volume Control Security Knobs: YA-920
APPLICATIONS
Airports
Audio/Visual
Auditoriums / Theatres
Banks
Bars / Lounges / Nightclubs
Boardrooms
Business Music
Conference Facilities
Convenience Stores
Educational Facilities
Fitness Clubs / Gymnasiums
Hotels / Hospitality
Houses of Worship
Industrial / Warehouses
Museums
Music Distribution
Offices
Public Address
Restaurants
Retail Stores
Theme Parks
Training Rooms
