16. SPECIFICATIONS
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Model No. BA-235 BA-260
Power Source 120 V AC, 60 Hz
Rated Output 35 W 60 W
Power Consumption 90 W (rated output) 130 W (rated output)
52 W (based on cULus standards) 66 W (based on cULus standards)
Frequency Response 50 Hz – 20 kHz
Total Harmonic Distortion 0.5% or less, at 1 kHz, rated output
Input Line input
Input Sensitivity/ Line input: 0 dB*/+4 dB* (selectable), 10 kΩ, unbalanced,
Impedance removable terminal block or RCA jacks
Output Speaker Output 4 Ω, 25 V (18 Ω) and 70 V (140 Ω)4 Ω, 25 V (10 Ω) and 70 V (83 Ω)
balanced, removable terminal block balanced, removable terminal block
Bridge Output Parallel in Line input, removable terminal block
Output Regulation (1 kHz)
Under 2 dB, no load to full load
S/N Ratio Line input: Over 80 dB
(Band Pass: 20 Hz – 20 kHz, Tone Controls: Centered)
Tone Control Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz
Control Master gain control
Bass tone control, Treble tone control
Input level selector switch
Remote volume control
Power ON/OFF switch
Indicator Power LED, Signal level LED, Peak LED
Other Feature Automatic electronic drive limiter
Operating Temperature 0 to 35 °C (32 to 95 ºF)
Operating Humidity 35 % to 80 % RH (no condensation)
Finish Panel: ABS resin, black
Case: Steel plate, black, paint
Dimensions 210 (w) x 94.3 (h) x 265 (d) mm (8.27" x 3.71" x 10.43")
Weight 4 kg (8.82 lb) 4.6 kg (10.14 lb)
YA-920 Volume control cover .................... 1
Removable terminal plug (2P) .................... 3
Removable terminal plug (4P) .................... 1
• Optional products
Rack mounting brackets : MB-25B-BK, MB-25B-J
15. DIMENSIONAL DIAGRAM
Unit: mm (in)
