Step 5. ConnectthelinesfromtheMT-200tothespeaker’srear-mountedconnector.
Forcableconnection,refertotheMT-200’sandtheHX-7Seriesspeaker’sOperatingInstructions.
Step 6. ReplacetheMT-200’scoverandtightenthescrews.
Securetheremovedcoverwiththe2coverfixingscrews.
Note
Toensurethesplash-proofcapability,pressthecoverrmlyontothegasket.
URL:http://www.toa.jp/
133-01-00038-00
5. SPECIFICATIONS
ApplicableSpeaker HX-7B,HX-7W,HX-7B-WP,HX-7W-WP
Finish Stainless,black,semi-gloss,paint
Dimensions 30(w)x70(h)x28(d)mm(1.18"x2.76"x11.02")
Weight 140g(0.31lb)
Note:Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
• Accessories
HexheadboltM6x16withspringandplainwashers....... 4
PlainwasherforM8............................................................ 2
NutforM8........................................................................... 2
