Step 3. MounttheMT-200tothisadapter.
Mount the MT-200 as shown in the gure at
right.Itscompletedinstallationisshowninthe
“MT-200MountingExample”gureonthefront
page.
Tip
BesuretokeeptheMT-200’scoverremoved.
Note
Wheninstallingspeakersystemsundereaves,
besuretoinstallinaverticalarray.Further,to
ensure the MT-200’s waterproong capability,
install it so that its top panel surface is tilted
within45ºoftheverticalplane.
If the MT-200’s waterproong capabilities
cannot be ensured by the mounting method
shown in the gure at upper right, mount the
MT-200asshownatlowerright.
Refertotheoperatinginstructionssuppliedwith
theMT-200.
MT-200 (without cover)
This adapter
Tightening torque:
8 N·m
Hex head bolt (supplied
with the MT-200)
Plain washer for M8
(accessory)
Nut for M8
(accessory)
Step 4. Mountthisadaptertotherearpanelofthespeakermodule.
This adapter can be attached to any
speaker module, however there may be
cases in which they cannot be easily
attached due to their combination with
otheroptionalmountingbrackets.Insuch
cases, attach this adapter to any free
speakermodule.
This adapter
Hex head bolt M6 x 16
(with spring and plain
washers, accessory)
Tightening
torque: 3 N
·m
MT-200
45°
45°
UP
Top surface
MT-200 (without cover)
Tightening torque:
8 N·m
Hex head bolt (supplied
with the MT-200)
This adapter
Plain washer for M8
(accessory)
Nut for M8
(accessory)
