Speaker
(side panel)
Machine screw M4 x 10 (accessory)
Side cover (accessory)
Note
The figure above shows an example for attaching the
covers to the upper side (Mounting Bracket A side).
Follow the same procedure to attach other side covers.
Step 11. Attach the supplied side covers.
Attach the supplied side covers to the upper side (Mounting Bracket A side), the lower side
(Mounting Bracket B side), and the input terminal section. (5 points)
To Next Page
