SPECIFICATIONS 13
2
ENOM00301-0
Remark: Specifications subject to change without notice.
*1 With propeller, with battery cable.
*2 With Manual Start
Tohatsu outboard is power rated in accordance with ISO8665 (propeller shaft output).
MF, EF, EFT
Item MODEL
F9.9E/15E/20E
MF EF EFT
Overall Length mm (in) 1038 (40.9)
Overall Width mm (in) 343 (13.5) 339 (13.3)
Overall Height S·L·UL mm (in) 1116 (43.9) 1258 (49.5) 1386 (54.5)
Transom Height S·L·UL mm (in) 413 (16.3) 562 (22.1) 689 (27.1)
Weight*1
S kg (lb) 43 (95) 47 (104) 52.5 (116)
L kg (lb) 44 (97) 48 (106) 53.5 (118)
UL kg (lb) 45.5 (100) 49.5 (109) 55 (121)
Output kW (ps) 9.9E : 7.3 (9.9) 15E : 11.0 (15) 20E : 14.7 (20)
Max. Operating Range
min
-1
(rpm)
5400-6100
Idle Speed in Forward Gear
min
-1
(rpm)
950
Idle Speed in Neutral Gear
min
-1
(rpm)
950
Engine Type 4-Stroke FI
Number of Cylinder 2
Bore × Stroke mm (in) 61 × 57 (2.40 × 2.24)
Piston Displacement cm
3
(Cu in) 333 (20.32)
Exhaust System Through hub exhaust
Cooling System Water cooling
Engine Lubrication Trochoid pump
Starting System Manual Electric starter motor*2
Ignition System Flywheel Magneto C.D. ignition
Spark Plug NGK DCPR6E
Trim Position 6 5
Engine Oil mL (fl.oz.) API, SH, SJ or SL SAE 10W-30/40, Approx. 1000 (33.8)
Gear Oil mL (fl.oz.) Genuine Gear Oil or API GL5, SAE #80-90, Approx. 465 (15.7)
Fuel Unleaded Regular Gasoline : R+M/2: 87 or higher RON: 91 or higher
Fuel Tank Capacity L (US gal) 12 (3.17)
Gear Reduction Ratio 2.15 (13 : 28)
Emission Control System MFI (Multiport Fuel Injection)
Operator Sound Pressure
(ICOMIA 39/94) dB (A)
84.2
Hand Vibration Level
(ICOMIA 38/94) m/s
2
2.5
