3
Switch Functions When Interfacing With a 940-AMP
Auxiliary Switch 1 Amp Output 7 +12Vdc
Auxiliary Switch 2 Amp Output 6 +12Vdc
Auxiliary Switch 3 Amp Output 5 +12Vdc
Auxiliary Switch 4 Amp Output 4 +12Vdc
Auxiliary Switch 5 Amp Output 3 +12Vdc
Auxiliary Switch 6 Amp Output 2 +12Vdc
Slide Switch Position 1 Amp Output 10 +12Vdc
Slide Switch Position 2 Amp Output 10+9 +12Vdc
Slide Switch Position 3 Amp Output 10+9+8 +12Vdc
Arrow Switch Amp Output (18)>(17)>(18,17) +12Vdc
Dim Switch Amp Output 1 -12Vdc
Manual Switch Activates Siren/Secondary Tone
Horn Switch Activates Electronic Air Horn
Rotary Switch Siren Tone Selection
Default Switch Configurations:
Slide Switch Position 0 OFF
Slide Switch Position 1 Mode 1
Slide Switch Position 2 Mode 1 + Mode 2
Slide Switch Position 3 Mode 1 + Mode 2 + Mode 3
Auxiliary 1 Toggle ON/OFF
Auxiliary 1 Toggle ON/OFF
Auxiliary 1 Toggle ON/OFF
Auxiliary 1 Toggle ON/OFF
Auxiliary 1 Toggle ON/OFF
Auxiliary 1 Toggle ON/OFF
Auxiliary 6 Momentary
Arrow Switch Toggle LEFT > RIGHT > CENTER OUT > OFF, hold
ARROW button for more than 1 Second to shut off.
DIM Switch Toggle-ON/OFF and Illuminated when low intensity activated
PROGRAMMING THE 948L-DCP:
To enter Programming Mode set the Rotary Switch to STAND-BY, press and hold the MANUAL and
HORN buttons simultaneously for 2 seconds . AUXILIARY 1 through 6 will flash 3 times to indicate
successful activation of programming mode.
