Tomberlin FireFox 620 - Service and Torque Specifications; Service Intervals and Torque Chart

Service Intervals
Interval
(Months)
Service
Date
Service Performed By: Type of Service
1
3
6
12
18
24
30
36
42
48
54
60
Torque Chart
FASTENER
Thread Size
TORQUE
(ft/lbs/in lbs)
T O R Q U E
(Nm)
5 mm bolts and nuts 39-52 in lbs 4.5-6 Nm
6mm bolts and nuts 69-104 in lbs 8-12 Nm
8mm bolts and nuts 13-18 ft lbs 18-25 Nm
10 mm bolts and nuts 22-29 ft lbs 30-40 Nm
12 mm bolts and nuts 36-43 ft lbs 50-60 Nm
4 mm screws 22-30 in lbs 2.5-3.4 Nm
5mm screws 30-43 in lbs 3.5-5 Nm
6 mm hex bolts 87-121 in lbs 10-14 Nm
8 mm hex bolts 17-22 ft lbs 24-30 Nm
10 mm hex bolts 25-32 ft lbs 35-45 Nm
