8.9 Folding Handlebar Column.
The Handlebar column can be folded before or after the Two-Piece Frame is
Dissembled.
To fold the handlebars, align the wheel with the frame then fully pull the latch
lever away from the column. Slide the lever sideways, to the left, to release the
interlock; then the handlebars can be folded. To reset, unfold the handlebars and
close the release lever. The interlock will automatically operate. See Maintenance
for adjustment instructions.
8.10 "Height and Reach" Adjustable Handlebars (Optional)
In combination with the sliding seat, the handlebars can be adjusted to achieve a
comfortable "reach" for the rider. To adjust, slide the button of the clamp
interlock to the open position, then pull the lever open. The handlebars can now be
moved and rotated to the desired position. Close the lever to re-lock.
8.11 Removable Mudguards. (Optional)
Removable mudguards are an essential companion of removable wheels and must be
removed before the wheels are disassembled. To do so, pull out the small plunger
where the mudguard attaches to the frame and lift the mudguard off the vehicle.
The plunger will automatically operate when refitting. It is good practice to
protect the mudguard during transportation with a towel or similar.
