Service

Manual

BIO meter AL-100

Doc. No

(4) Remove 4 set of screws (M3*6) that

hold base LCD.

(5) Turn LCD unit and hold it by hand.

And remove 3 set of screws (M3*6)

that hold shield LCD.
