OPERATION MANUAL
www.thetoolshed.co.nz
SPECIFICATIONS
CC Rating 42.7
Power 1.1KW
Fuel Mixture 25-1
Weight 6.6KG
Fuel Capacity 1.2L
IDENTIFICATION
1 Engine unit 11 Air filter 21 Saw chain
2 Shoulder harness 12 Choke 22 Cutting unit
3 Handle 13 Spark plug cap 23 Adjusting handle
4 Extension tube 14 Switch 24 Adjusting handle lock
lever
5 Hedge trimmer head 15 Brush cutter head 25 Brush cutter head
6 Chainsaw head 16 Throttle lock 26 Jointer
7 Fuel tank cap 17 Throttle 27 Bar cover
8
Primer bulb
18
Guide bar
28
Blade cover
9 Starting handle 19 Adjusting screw
10
Fuel tank
20
Oil tank
