4. Lubricate the spindle of the polisher before installation if possible. Make sure
that there is no guard lever around the collar of the polisher.
5. While planetary polisher base is on a flat surface, insert the spindle of the
polisher into the input shaft horizontally.
Tip: When trying to thread the spindle into the input shaft install one of the back holders and
turn it clock wise. The spindle should tighten into the input shaft easily.
if possible
Polisher spindle
Threaded input shaft
Collar
To Next Page
