Spray nozzle tip

Pull quick

connect collar

down

Spray wand

CONNECT / DISCONNECT NOZZLES (PIC. 9)

Connect

1. Pull down QC collar

2. Push nozzle into hole

3. Release QC collar

4. Pull nozzle to ensure it is locked in position

Disconnect

1. Pull down QC collar

2. Lift nozzle out

3. Release QC collar

RED GREEN WHITE BLACK

SELECTING NOZZLE

Red 0º

This nozzle is for high pressure and proves a single “pencil” stream of water.

Green 25º

This nozzle is for high pressure and provides a wide 25º “fan” of water.

White 40º

This nozzle is for high pressure and provides the widest 40º “fan” of water.

Black

This nozzle is for low pressure and for use with

detergent tube.
