TOORX BRX3000 - Page 7

STEP 1
Step-1
D15.4
M8*20
D16
9
7
x8
8
4
1
2
9
8
7
4
23
1) Assemble the front stabilizer (4) and rear stabilizer (2) to the main frame (1) by
using the flat washer (7), spring washer (8) and Allen bolt (9).
2) Adjust the proper height by turning the wheel of rear foot cap (3).
8
