Pre-assembly Notes
Open the boxes:
Make sure to inventory all the parts that are included in the box. Check the hardware
chart
of a full count of the number of parts included for proper assembly . If any of the parts
are
missing, contact with the dealer.
NO. NAME SPECIFICATION QTY
29 Allen C.K.S. half thread screw M8×50×20 4
30 Spring washer Φ8 6
31 Flat washer Φ8.5×Φ20×t1.5 6
32 Allen C.K.S. full thread screw M8×20 1
33 Curved washer Φ8.5×R25×t2.0 1
To Next Page
