34 Allen C.K.S. half thread screw M8×63×20 2
35 Hex self-locking nut M8 1
36 Philips C.K.S. self-tapping screw ST4×16 2
37 Philips pan head full thread screw M4×6 4
38 Philips pan head full thread screw M5×10 4
39 Philips pan head full thread screw M4×10 4
GATHER YOUR TOOLS
Before starting the assembly of your unit
，
gather the necessary tools.Having all of the
equipment at hand will save time and make the assembly quick and hassle-free.
CLEAR YOUR WORK AREA
Make sure that you have cleared away a large enough space to properly assemble the
unit. Make sure the space is free from anything that may cause injury during assembly.
After the unit is fully assembled, make sure there is a comfortable amount of free area
around the unit for unobstructed operation.
NOTE: Each step number in the assembly instructions tells you what you will be doing.
Read and understand all instructions thoroughly before assembling the treadmill.
