TOORX ERX3000 - Page 8

20
21R
73
77
11
20
21L
11
73
77
20
73
77
b
a
(x4)
Step-2
M6*1*45L D14 D40
1) Assemble the left and right pedal (21L&21R) on the pedal supporting tube (11) by
using the flat washer (73), the knob (77) and square bolt (20).
2) 3 optional positions for the pedals you can choose.
13
STEP 2
