A Attach one end of the 3150mm Upper cable (94#) through the opening of the upper frame , Make
sure that the ball stopper should be in front of the U shape bracket. Place the 1
st
Pulley (79#) below
the cable and secure the 1
st
pulley using 1PCM10 × 45 Allen bolt (35#) ,2PC φ10 washers(44#)and
1XM10 Aircraft nut (46#).
B Draw the cable backwards and place the 2
st
pulley below the cable , Secure the pulley with the same
way in A.
C Draw the cable around the pulley and front , Place the 3
st
pulley below the cable and secure them
with 1PC M10×140Allen bolt (28#), 2pcs φ10 washers(44#),and 1 pc M10 Aircraft nut(46#).
D Draw the cable around the pulley and backwards,Place the 4
st
pulley below the cable and secure it
with the same way in A.
E Draw the cable around the pulley and downwards,Place the 5
st
pulley onto the cable, Secure the
pulley with double floating pulley bracket(23#) together with the 1pc M10*50 Allen Bolt(33#),2pcs φ10
washers(44#),2 pcs bushing(81#), 2 pcs retainer(80#),and 1 pc M10 Aircraft nut(46#).
F Draw the cable around the pulley and upwards ,Place the 6
st
pulley below the cable and secure
them with 1PC M10*65 Allen bolt(31#), 2PC bushing(47#) and 1 pc M10 Aircraft nut(46#).
G Draw the cable around the pulley and downwards,thread the end of the upper cable to the top
opening of the selector rod at least 5 laps to keep safe.
Select the desired weight when exercising using the L shape Lock pin.
