A Attach the 4600 mm lower cable(95#) through the opening of the leg developer,place 1
st
pulley onto
the cable and secure the pulley with 1PC M10X65 Allen bolt (31#),2pcs Bushing (47#)and 1pc M10
Aircraft nut (46#).
B Draw the cable backwards and place the 2
st
pulley below it , Secure the pulley with the same way in
A.
C Draw the cable around the pulley and backwards again, place 3
st
pulley onto it , Secure the pulley
with the same way with M10*45 Allen bolt (35#) and 2 PCS φ10 washers (44#) and 1 pc M10 Aircraft
nut (46#).
D Draw the cable around the pulley and place the 4
st
pulley below the cable,Secure the pulley with the
way C.
E Draw the cable around the pulley and downwards,Place the 5
st
pulley onto the cable and secure the
pulley with 1PC M10X60 Allen bolt (32#),2pcs Bushing (48#)and 1pc M10 Aircraft nut (46#).
F Draw the cable around the pulley,Place the 6
st
pulley onto the cable and secure the pulley with the
same way C.
G Draw the cable around the pulley and place the 7 th pulley below the cable, ,Secure the it with the
same way in Step 10 B procedure.
H Draw the cable around the pulley and repeat the F to secure the pulley .
I Draw the cable around the pulley and upwards,Secure the puley with the double floating pulley
bracket together with the same way in STEP 9 E.
J Draw the cable around the pulley and reach the U shape Bracket ,Secure it with 1pcM10*28 Allen
bolt(36#),2 PCS φ10 washers (44#) and 1 pc M10 Aircraft nut (46#).
