TOORX SRX3500 - Part List

Part list
Part NO. Description Material Specification QTY
1 Main frame 1
2 Front stabilizer 1
3 Rear stabilizer 1
4L Tri-angle cap(left) PE 95.7*57.2*51.3 2
4R Tri-angle cap(right) PE 95.7*57.2*51.3 2
5 Allen bolt SUS304 M8x1.25x20L,8.8 8
6 Spring washer SUS304 D15.4xD8.2x2T 8
7 Flat washer SUS304 D16xD8.5x1.2T 10
8 Seat post 1
9 Seat post 1
10 Seat VL-3230 1
11 Seat adjustable tube 1
12 L knob AL+45# M12*25L 2
13 Handlebar 1
14 Computer fixing plate 1
15 D cap PS 70*45*14 1
16 Cover of handlebar post PE 80*55*147 1
17 Protective cover PE 80*55*61 1
18 Inner cover PE 80*55*147 1
19 Stop plate(1) AL 39*35*17 2
20 Spring 72A D12.5*D1.2*20.7 2
21 Stop plate(2) AL 38*35*17 2
22 L knob 50L AL+45# M10*50L 2
23L Left chain cover ABS 744.3*512.4*77.7 1
23R Right chain cover ABS 1
24L Left crank 1021M 170*9/16"-20BC 1
24R Right crank 1021M+SPH 170*9/16"-20BC 1
25L/R Pedal JD-037V,9/16" 1
26 Bolt 35# M8x1.0x16,10.9 2
27 Screw cover P.E6070 D23x6.5 2
28 Screw SUS304 M10*1.5*20L 5
29 Nut SUS304 M10*1.5*8T 5
30 Bolt Q235A M5x0.8x15L 2
31 Buffer SBR D9*D5.8*13 2
32 Screw 10# ST4.2*1.4*20L 9
33A Screw Q235A M5x0.8x10L 1
33B Screw Q235A M5*0.8*20L 1
8
