Top Gin TG250 - 1.2 Identifying the Parts

5
Symbol Enclosure
0 Open shdssis type (IP00)
1 Enclosed wall-mounted type(IP20)
Symbol Specification
T Standard
E CE mark
U UL
Digital Operator
Front Cover
Protective Cover (top/bottom)
4 Mountin
g
Holes
Ventilation Slots
●Model Designation
TG – 300 – L 100 – A 2 T 1
TOP GIN
IGBT Series
1.2 IDENTIFYING THE PARTS
Flg. 4 Configuration of TG-300
Symbol Voltage
L
3φ220V Series
H
3φ440V Series
Max applicable motor
output (10Hp)
A：
Without
Braking
resitstor
B：With
Operator
1 Black
2 Digital with
VR
3 LCD with VR
