3. WIRING
WAR IN G
●Only commence wiring after verifying that the power supply is turned OFF.
Failure to observe this warning can result in an electrical shock or a fire.
●Wiring should be performed only by qualified personnel.
Failure to observe this warning can result in an electrical shock or a fire.
●When wiring the emergency stop circuit, check the wiring thoroughly before operation.
Failure to observe this warning can result in personal injury.
CAUTION
●Verify that the inverter rated voltage coincides with the AC power supply voltage.
Failure to observe this warning can result in personal injure or a fire.
●Do not perform a withstand voltage test of the inverter.
It may cause semi-conductor elements to be damaged.
●To connect a braking resistor, braking resistor unit or braking unit, follow the procedures described
in APPENDIX 3.
Improper connection may cause a fire.
●Tighten terminal screws to the specified tightening torque.
Failure to observe this caution can result in a fire.
This chapter describes the main circuit wiring and the control circuit wiring of the TG-300.
