4) Then fasten the abdominal “automatic” fastener in order to fasten the belt. Adjust the belt’s fabric straps. When in place, the back belt must cover the
small of the back and not move when you carry out movements. Adjust the fabric straps of the shoulder straps.
5) Fasten the leg supports around each of your thighs using the “automatic” fasteners. Then adjust the leg supports using the fabric straps.
6) None of the fabric straps must be twisted when you have finished assembling the harness.
7) Use the D-ring at the back as point of attachment to fall arrest systems that is required according to the application. To locate the attachment elements in
the harness, check for the separately stitched label showing the ‘A’ marking near the attachment elements. Do not use any other point as an attachment
element for fall arrest. When the logo ‘A2’ is on the shoulder strap, it means that the two buckles must be used together as anchorage point.
In case of any doubt arising about the condition of any component or system, replace it immediately. If the item has already arrested a fall, withdraw it from
service & return it to the manufacturer or to a competent repair centre.
Before use, insure that there is a minimum clearance of 5ms below the user’s feet, to avoid him hitting the ground in case of fall. Moreover, ensure that
there is not obstacle between the user and the ground to avoid collision in case of fall. A rescue plan has to be set up before use, for carrying out a rescue
operation in case of emergency.
It’s really important to regularly check the fastening and the fitting of each element during the use. The lanyard must be adjusted so that the anchorage
point is at the waist level of the user or above. The lanyard must be taut and the free movement limited at 0.6m.
PERFORMANCE AND LIMITATIONS OF USE
Clause4.1 Design et Ergonomics
Clause 4.2 Matérial
Clause 4.3 Static Strength
(EN 364:1993 Clause 5.1.4)
Clause 4.4 Dynamic performance
(EN 364:1993 Clause 5.1.2)
-- Concidered to be sufficiently light and likely to remain in place during use without becoming incorrectly adjusted
without the wearer knowledge. (PASS)
- Material type specified on label as Polyester – application of nacked flame to webbing and thread resulted in melting
consistent with synthetic material (PASS)
- Blue webbing with white thread (PASS)
- Straps present in pelvic and shoulder areas. (PASS)
- Primary straps 43mm / Secondary straps 20mm. (PASS)
- Fall arrest attachment at centre of back only. (PASS)
- White rust on buckles after 24 hours of neutral salt spray (Ductile Stell processors UKAS), Testing 0561 certificate
118157. (PASS)
- Dummy not release when an upward force of 15kN was applied for 3 minutes. (PASS)
- Dummy not release when a downward force of 10kN is applied for 3 minutes. (PASS)
- Feet first drop dummy restrained at angle of 0° to the vertical. (PASS)
- Head first drop dummy restrained at angle of 0° to the vertical. (PASS)
Clause 4.1 Design et Ergonomcs
Clause 4.1.3 Matérial
Clause 4.2.1 Static Strength
Clause 4.4 Dynamic Performance
MATERIAL USED: The entire webbing used in this harness is made up of polyester.
WARNING: Be sure that the user information of the harness are compatible with the other components of the safety system as lanyards or connectors.
A harness is the only element wich can be used in a fall arrestor system. It must be used with a fall arrestor system such as energy absorber EN355 or
retractable fall arrestor EN360.
COMPATIBILITY: To optimise protection, in some instances it may be necessary to use the belt with suitable boots/gloves/helmet/ear defenders. In this
case, before carrying the risk-related activity, consult your supplier to ensure that all your protective products are compatible and suitable for your
application. Also ensure that the product is used by a trained and competent person. A risk can appear during the use of several items of equipment in which
the safety function of one item of equipment is affected by the safety function of another. Please consult the UIS of the energy absorber (if you use one) to
check the minimum clearance advised.
A fall arrest harness is the only equipment which is allowed to use in a fall arrest system and must be used with a fall arrest system such as an energy
absorber conforming to EN355 or EN360. Check adjustment and/or fastener elements during the use. The equipment shouldn’t be use for fall arrest and it
can be necessary to complete the work positioning system with collective (for example safety net) or individual (for example fall arrestor system) protection
equipments against height fall.
Extreme temperatures, allowing lanyards or anchorage lines to lie or roll on cutting ridges, chemicals reactions, electrical conductivity effects, cutting,
abrasive and climatic effects can change the equipment’s performance.
STORAGE AND TRANSPORT: When not in use, store the work position belt in a well-ventilated area away from extremes of temperature. Never place heavy
items on top of it. If possible, avoid excessive folding and preferably store it hanging vertically. If the product is wet, allow it to dry fully before placing it into
storage.
REPAIR: if the product becomes damaged, it will not provide the optimum level of protection, and therefore should be immediately either replaced or
repaired. Never use the damaged product. Repair is permitted, provided that it is either done by the manufacturer or a competent repair centre approved
by the manufacturer.
CLEANING: In case of minor soiling, wipe the work positioning belt with cotton cloth or a soft brush. Do not use any abrasive material. For intense cleaning
wash the harness in water at a temperature between 30°C to 60°C using a neutral detergent (pH = 7). The washing temperature should not exceed 60°C. Do
not use acid or basic detergents. Follow the washing instruction absolutely without any deviations.
MARKING:
1- TOP LOCK logo 6- Years of manufacture
2- Product reference number 7- Lot n°
3- Size 8- Serial Number
4- The CE marking showing that the product meets the requirements 9- Read the UIS
of the European Directive 89/686 + n° of the notified body. 10- Product composition
5- N° of the standard
LIFETIME: the lifetime of the equipment is maximum 10 years from date of manufacture, but a pre-user check must be done before use, and an inspection
must be carried out by a competent person at least once a year. The lifespan of the product depends essentially of his condition of use.
CHECKING CARD : A periodical examination must be realized given that the safety of the user depends of the performance and of the resistance of the
equipment. It’s recommended to realize a periodical examination at least once each twelve months. A periodical examination must be realized by a
competent person and in the strict respect of the way detailed by the supplier. Observations must be written in the box bellow. In the case where some
defects are observed, the equipment must be immediately replaced. The marks must be controlled during the periodical examination. If they are not legible,
the equipment must be removed and replaced. This product must be used in a fall arrest system conforms to the standard EN363:1993 in combination with
a fall arrestor on an anchorage line conforms to the standard EN353-2:2002 or with a energy absorber conforms to the standard EN354:2002 and
EN355:2002 or with a retractable fall arrest system conforms to the standard EN360:2002. The user instructions of each individual component must be
checked too.
SERVICE and INSPECTION RECORD
IDENTIFICATION : It’s recommended to keep an identification card for each elements or each system, which contains the following information :
It’s important for the safety’s user that this sheet was written in the official language of the country. If it’s not, please contact WORLDWIDE EURO
PROTECTION.
Zertifizierungseinrichtung: SATRA Technology Europe Ltd, Bracetown Business Park, Clonee, Co. Meath D15 YN2P, Ireland (Einrichtung Nr.
2777)
Zuständige Prüfstelle: SGS Fimko Oy, P.O. Box 30 (Särkiniementie 3), 00211 HELSINKI, Finland (Einrichtung 0598)
LESEN SIE DIESE GEBRAUCHSANWEISUNG VOR DER VERWENDUNG DES PRODUKTS AUFMERKSAM DURCH
Das komplette Geschirr wurde entwickelt, um die Risiken zu minimieren und/oder möglichst großen Schutz gegen die Gefahr von Stürzen aus der Höhe zu
gewähren. Es ist jedoch wichtig, daran zu erinnern, dass keine individuelle Schutzausrüstung absoluten Schutz liefern kann und während der Ausübung der
riskanten Tätigkeit stets mit Vorsicht verwendet werden muss. Die CE-Kennzeichnung auf diesem Artikel bestätigt die Einhaltung der wesentlichen
Anforderungen der Europäischen Richtlinie Nr. 89/686/EEC, Anhang II bezüglich der individuellen Schutzausrüstung; eine Zertifizierung gemäß der Norm EN
361:2002 liegt vor.
Klausel 4.1 Design und
Ergonomie
Klausel 4.2 Materialien
Klausel 4.3 Statische Kraft
(EN364:1993 Klausel 5.1.4)
Klausel 4.4 Dynamische
Leistung
(EN 364:1993 Klausel 5.1.2)
- Wird als ausreichend leicht und in der Lage angesehen, während der gesamten Nutzungsdauer am Platz zu bleiben;
kann nicht falsch angepasst werden, auch nicht ohne besondere Nutzungskenntnisse. (konform)
- Materialart auf dem Label als Polyester angegeben – wenn Gurt und Faden einer Flamme ausgesetzt werden, führt
dies zu einem Schmelzen wie bei Synthetikmaterialien. (KONFORM)
- Blaue Gurte mit weißen Fäden bestickt. (konform)
- Gurte im Becken- und Schulterbereich. (KONFORM)
- Hauptgurte 43 mm / Nebengurte 20 mm. (KONFORM)
- Befestigung zum Abfangen von Stürzen nur in der Rückenmitte. (KONFORM)
- Weißer Rost auf den Schnallen nach 24 Std. Besprühen mit einem neutralen Spray. Test 0561 Zertifikat 118157.
(KONFORM)
- Der Dummy bleibt am Platz, wenn das Geschirr 3 Minuten lang einer Kraft von 15 kN nach oben ausgesetzt wird.
(KONFORM)
- Der Dummy bleibt am Platz, wenn das Geschirr 3 Minuten lang einer Kraft von 10 kN nach unten ausgesetzt wird.
(KONFORM)
- Wenn der Dummy mit den Füßen voraus fällt, bleibt er in einem Winkel von 0° zur vertikalen Position. (KONFORM)
- Wenn der Dummy mit dem Kopf voraus fällt, bleibt er in einem Winkel von 0° zur vertikalen Position. (KONFORM)
Klausel 4.1 Design und
Ergonomie
Klausel 4.1.3. Materialien
Klausel 4.2.1 Statische Kraft
Klausel 4.4 Dynamische
Leistung
KONFORM
KONFORM
KONFORM
KONFORM
1. Das komplette Geschirr mit Hüftgurt ist allein Eigentum des Nutzers.
2. Der Hüftsitzgurt darf nicht in einer stark basischen oder säurehaltigen Umgebung verwendet werden.
3. Der Nutzer ist dafür verantwortlich, sein Produkt sowohl während der Verwendung als auch während des Transports und der Lagerung gegen
mechanische Gefahren wie scharfe Kanten, Werkzeuge, lange Sonneneinstrahlung und UV-Schädigung zu schützen.
Date Damages Observed Repair Measures Comments
1. Type 5.Date of purchase
2. Identification marking 6.Date of first use
3. Tracking number 7.User Name
4. Year of manufacture 8.Next periodical examination date :
