Connectors
Main: Tyco-AMP 1437288-6
Mating connector (customer)
Tyco-AMP 3-1437290-7
Mating crimp contact (customer)
Tyco-AMP 3-1447221-4
Dummy Plug (customer)
Tyco AMP 4-1437284-3
Video: M12 round connector, female, 5-pole,
B-coded, acc. to EN 61076-2-101
Recommended mating connector type according
to IEC 61076-2-10: MM 005-Gx1-B
x) A, C, I, P, R or S-type
7 Connectors
Ethernet: M12 round connector, female,
4-pole, D-coded
acc. to EN 61076-2-101
Recommended mating connector type according
to IEC 61076-2-10: MM 004-Gx1-D
x) A, C, I, P, R or S-type
6 Interfaces
CAN Bus
2 x CAN-Interfaces according to ISO 11898, CAN-
specification 2.0 B active, up to 1 Mbit/s (default
250 Kbit/s, 500 Kbit/s, 750 Kbit/s and 1 Mbit/s)
RS232
1 x RS232-Interface
Type: EIA232 (only RxD, TxD, GND)
Speed: max. 115 Kbps
USB
Host 2.0
Main connector: 1 x Full speed typ. 150 mA
On front: 1 x USB slot High speed
Inputs
4 configurable analog/digital inputs
Input impedance: > 3k Ohm
Resolution: 10 bit (1028 digits,
1 digit = 11,7 mV)
Voltage range: 0 … 12 V
Over-voltage protection: Up to 36 V DC
Short circuit protection: Up to 36 V DC
Frequency: Max. signal frequency
50 Hz
Outputs
3 digital outputs
Short circuit protection: Up to 36 V
I
max
300 mA open drain
R
DS,on
< 1 Ohm
R
DS,off
> 100 kOhm
Video-Interface
Inputs: 1x analog
V
ss
: 1 V
Camera supply: 12 VDC
Max. current: 500 mA
Ethernet-Interface
1 x 10/100 Mbit/s Base T
