NO. Name Descriptions
1 Indicator light
Three LED indicators are provided on each side, and the
prompts are as follows:
•
Power: Red lights to indicate that the power is on
•
Vehicle: Green flashing means it is communicating with the
vehicle
•
I/O: Purple, long light means the USB is connected to the
host
2 DB30 diagnostic port
Plug in the diagnostic cable whose OBD 16-pin connector is
linked to the DLC of the vehicle.
3 Type-C port
Type-C port is designed for building stable communication
while ECU Programming or IMMO Key Programming.
2
1
3
