Topdon Phoenix Lite 2 - Product Descriptions: MDCI Dongle; Indicator Light and OBD Port

6
NO. Name Descriptions
1 Indicator Light
Three LED indicators are provided on each side, and the
prompts are as follows:
•
Power: Green light indicates power on.
•
Connect:Blue light means that it has been connected to the
device by bluetooth.
•
Vehicle: Blue flashing shows that it is communicating with
the vehicle.
2 OBD Port
Plug in the diagnostic cable whose OBD 16-pin connector is
linked to the DLC of the vehicle.
2
1
