Sensitivity Cold start: -149 dBm
Tracking: -163 dBm
Position Accuracy in open sky (CEP-50) < 2m
Standalone TTFF Cold start: < 29s
Warm start: < 27s
Hot start: < 1s
Interfaces
Charging and Data Transmission 4 Pin port with magnet
Network, GNSS Antenna Internal only
Indicator LED Network, GNSS and Battery
FOTA Yes
Physical Power Switch 1
Light Sensor 1 back light sensor
Temperature Sensor 1 temperature sensor
BLE 5.0 Yes
General Specifications
Waterproof IP67
Dimensions 85mm*185mm*31 mm (3.35” *7.28” *1.22”)
Weight 370g (13oz)
Battery Rechargeable Li-Polymer 9600 mAh/ 3.6V
Standby Time
(without solar charging, 2 hours active
tracking per day)
10 minutes reporting: 320 Days
5 minutes reporting: 170 Days
1 minute reporting: 68 Days
Charging & Data Communication Magnetic USB cable
(recommend using 5V 1A adaptor, 20 hours
charging)
Operating Temperature -25℃ ~ +70℃ (-13°F ~ 158°F)
Mounting Magnet/Screw
Air Interface Protocol
Transmit Protocol TCP, UDP, MQTT, SMS
Data Security & Encryption Option MD5/ AES256
BLE Accessory Support Yes
Scheduled Timing/angle/distance Report Report position and status at preset intervals
Geo-fence Support up to 64 internal geo-fence regions
Alarms Support up to 31 types of alarm
(refer 7. Alarm Configuration)
3. Standard Accessories Introduction
USB cable
