TOPIC-LIGHT COB200W - DMX Mode 7 (7 Channel)

LED ZOOM
10
4.7.
DMX Mode 7 (7 Channel)
DMX Channel DMX Value Function
1. White Dimming
1~255
Turn on the light and White Dimming
and color is controlled by CH2, 3, 4, 5
2. W1 Dimming
1~255
Adjust LEDs dimmer low to high
3. W2 Dimming
1~255 Adjust LEDs dimmer low to high
4. W3 Dimming
1~255 Adjust LEDs dimmer low to high
5. W4 Dimming 1~255 Adjust LEDs dimmer low to high
6. STROBE 1~255
Adjust strobe low to high (the color is
controlled by CH2-CH5).
7. Linear and curve lighting
option
0~9 Linear
10~255
6 selectable dimming curves
10~49 1s; 50~99 2s; 100~149 3s;
150~199 4s; 200~249 5s;
250~255 6s
PAR64 COB 200W 3200K IP X4
