TOPIC-LIGHT COB200W - Page 6

LED ZOOM
6
WHILE IN MASTER-SLAVE MODE, ONLY ONE HOST MACHINE CAN BE EXISTED, IF NOT, IT
MAY CAUSE SIGNAL CONFLECTS.
DMX CHANNEL SETTING
DMX ADDRESS SETTING
SINGLE MODE SETTING:
C 1
C 2
C 3
C 4
C 5
C 6
C 7
D 0 0 1
F 0 0 0
F 0 1 0
——>Default in C1, DMX Channel: CH. 1
——>DMX Channel: CH. 3
——>Press “MODE” to begin your setting, and press “ENTER” to select the mode.
Select the UP/DOWN from F010～F120, press “ENTER” to save your setting.
Original setting “F000”, the light goes off.
——>Default in D001, DMX Address from “D001-D512”, Press “ENTER” to
save the setting.
——>DMX Channel: CH. 5
——>DMX Channel: CH. 6
——>DMX Channel: CH. 7
——>SINGLE WHITE F010~F019 strobe, speed low to high
——>DMX Channel: CH. 2
——>DMX Channel: CH. 4
PAR64 COB 200W 3200K IP X4
