Topper Topaz 16C - Page 5

ATTACH TRAMPOLINE TO FRONT BEAM
A. Tie the front end of trampoline onto slug on front beam.
B. Pull tight, so end pulley wheel is tight in the back end of
the trampoline.
C. Tie off to slug using a half hitch with a knot against it to
stop it slipping.
Repeat this on the opposite side.
ATTACH TRAMPOLINE TO REAR BEAM
A. (1) Attach trampoline tensioning lines to the deck eye on
rear beam.
B. (2) Feed forward & through pulley wheel at rear of trampoline.
C. (3) Back through deck eye. Tension as tight as possible.
Then repeat process, this time through the stainless steel ring
fixed to the back of the trampoline (4-5).
(6) Back through deck eye. Again, tension as tight as possible.
Tie off with a round turn and two half hitches.
Then repeat on opposite side. Ensure trampoline is as taut as
possible to ensure a firm platform.
TIGHTEN CENTRE OF TRAMPOLINE
A. Tighten centre of trampoline by (1) feeding rope through
deck eye left-to-right, then (2) up to and through right trampoline
eyelet, (3) through left eyelet and back down (4) through deck eye
(left to right).
B. (5-6) Then feed right hand tail up through right trampoline
eyelet and left hand tail up through left trampoline eyelet, tighten
and tie off with a reef knot.
C. Tidy tail ends by tucking back down through eyelets.
1
2
1
2
3
4
5
6
3
2
4
1
6
5
5
