TOPVERT G1/H1/P1 Series
E-1
PREFACE
Thank you for choosing TOPTEK’S TOPVERT G1, H1 and P1 Series Drive. TOPVERT G1, H1 and
P1 Series are Sensorless current vector control high-performance drive. They were manufactured by
adopting high-quality components, material and incorporating the latest microprocessor technology
available.
Copyright statement
All information in this Quick start manual are Toptek’s intellectual property. Even we had done our best
to make this manual but is unable to guarantee 100% correct.Based on " Never Stop for better but
perfect accomplished " quality policy, our product permanently in the journey which perfectly strives for
perfection to the pursue,Therefore we reserve the right to change the information in this manual
without prior notice.But we will continue the latest edition document in our website, for free download.
http://www.toptek.biz
Getting Started
This manual will be helpful in the installation, parameter setting, troubleshooting, and daily
maintenance of the drives. To guarantee safe operation of the equipment, read the following safety
guidelines before connecting power to the drives. Keep this operating manual handy and distribute to
all users for reference.
Always read this manual thoroughly before using TOPVERT G1,H1 and P1 Series drives.
DANGER!
1- AC input power must be disconnected before any maintenance. Do not connect or disconnect
wires and connectors while power is applied to the circuit. Maintenance must be performed by
qualified technicians.
2- A charge may still remain in the DC-link capacitor with voltages even if the power has been turned
off. To avoid personal injury, please ensure that power has turned off before operating drive and
wait ten minutes for capacitors to discharge to safe voltage levels.
3- The drive may be destroyed beyond repair if incorrect cables are connected to the input/output
terminals. Never connect the drive output terminals U/T1, V/T2, and W/T3 directly to the AC main
circuit power supply
CAUTION!
1- There are highly sensitive MOS components on the printed circuit boards. These components are
especially sensitive to static electricity. To avoid damage to these components, do not touch
these components or the circuit boards with metal objects or your bare hands.
2- Ground the drive using the ground terminal. The grounding method must comply with the laws of
the country where the drive is to be installed. Refer to Basic Wiring Diagram.
3- The final enclosures of the drive must comply with EN50178. (Live parts shall be arranged in
enclosures or located behind barriers that meet at least the requirements of the Protective Type
IP20.The top surface of the enclosures or barrier that is easily accessible shall meet at least the
requirements of the Protective Type IP40). (TOPVERT G1, H1 and P1 Series correspond with
this regulation.)
4- Heat sink may heat up over 70℃ (158℉), during the operation. Do not touch the heat sink.
5- The rated voltage for the drive must be ≤ 240V (≤ 480V for 460V models, ≤ 600VFor 575V models)
and the mains supply current capacity must be
≤ 5000A RMS (≤10000A RMS for the ≥ 40hp
(30kW) models).
6- The leakage current between chassis and earth could be up to 22mA.
7- The load motor should meet IEC:60034-1 standard.
W A R N IN G
