TOPVERT S1 Series
E-
11
0 Changed parameter will be store
Bit4
1 Changed parameter not store
0: Linear Acc, linear Dec.
1: Auto Acc, linear Dec.
2: Linear Acc, auto Dec.
3: Auto Acc, auto Dec.
Pr0-12
Auto Accelerate/
Decelerate
4: Linear Acc,/Dec., auto to prevent stall.
0
0: 0.01 Second
1: 0.1 Second
★
Pr0-13
Accelerate/ Decelerate
time unit
2: 1 Second
0
0=0.7kHz
Pr0-14
PWM Carrier frequency
upper bound
1〜18kHz
10
0=0.7kHz
Pr0-15
PWM Carrier frequency
lower bound
1〜18kHz
10
0: Enable Automatic Voltage Regulation
1: Disable Automatic Voltage Regulation
Pr0-16
Automatic Voltage
Regulation (AVR)
2: Disable Automatic Voltage Regulation while in
decele
0
0
Disable Automatic Energy-Saving
Operate
Bit0
1
Enable Automatic Energy-Saving
Operate
0
Allow output voltage over source
voltage
Bit1
1
Maximum output voltage equals to
source voltage
0 For constant torque load application.
Bit2
1 For variable torque load application.
0 Regen-torque no slip compensation
Bit3
1 Regen-torque with slip compensation
0 Low noise mode operation
Pr0-17
Automatic Energy-Saving
Operation (AESO)
and others
Bit4
1 Quiet mode operation
b00000
0: From PU
1: From RS485 communication port
2: From external analog signal
3: From external Up/Down terminals
Pr0-18
Source of the frequency
command
4: (Factory Reserved) ◎
0
0: From RS485 communication port or PU
1: From external terminals or PU
2: From PU
Pr0-19
Source of the operation
command
3: From external terminals
0
0 Ramp to stop
Bit0
1 Coast to stop
0 Terminal command not run after reset
Bit1
1
Terminal command restart after reset
0 Line start Lockout is enabled
Bit2
1
Line start Lockout is disabled
0 FWD/REV go through zero point
Bit3
1
FWD/REV go not through zero point
0 Linear Accel/Decel at high speed zone
Pr0-20 Stop/ Run/safety lockout
Bit4
1
S-curve Accel/Decel at high speed
zone
b00000
0: Enable Forward/Reverse operation
1: Disable Reverse operation
Pr0-21 Direction limit
2: Disabled Forward operation
0
