TOPTEK TOPVERT S1 Series User Manual

TOPVERT S1 Series
E-
17
16: Torque adjust
Pr3-03
AVI analog Input bias
-10.00〜10.00V 0.00
Pr3-04
AVI analog Input gain
-500.0〜+500.0% 100.0
0: Zero bias
1: Value lower than bias = bias
2: Value higher than bias = bias
Pr3-05 AVI analog Input bias mode
3: The absolute value of the bias voltage while
serving as the center
0
Pr3-06
ACI Analog Input (see Pr3-02)
Same as Pr3-02 0.00
Pr3-07
ACI analog Input bias
0.00〜20.00mA 4.00
Pr3-08
ACI analog Input gain
-500.0〜+500.0% 100.0
0：Zero bias
1: Value lower than bias = bias
2: Value higher than bias = bias
Pr3-09 ACI analog Input bias mode
3: The absolute value of the bias voltage while
serving as the center
1
0: Disabled
1: Continue operation by the last frequency comma
n
2: Decelerate to stop
Pr3-10 Loss of the ACI signal
3: Coast to stop and display AcI.
0
Pr3-11
(Factory Reserved)
(Factory Reserved)
0.00
Pr3-12
(Factory Reserved)
(Factory Reserved)
0.00
Pr3-13
(Factory Reserved)
(Factory Reserved) 100
Pr3-14
(Factory Reserved)
(Factory Reserved)
0
Pr3-15 Analog output 1 function (AVO) 0: Output frequency (Hz) 0
1: Command frequency (Hz)
2: Motor Speed
3: Output current (A rms)
4: Output voltage (VAC)
5: DC BUS voltage (VDC)
6: Power factor
7: Power
8: AVI (V)
9: ACI (mA)
10: (Factory Reserved)
11~12: (Factory Reserved)
13: Output voltage command
14: Counter Value
15: User defined value on Pr3-21
16~23: (Factory Reserved)
Pr3-16 (Factory Reserved)
24: Define to digital output (MOx) ◎
0
Pr3-17
AVO Analog output gain
-900.0〜900.0% 100.0
Pr3-18
(Factory Reserved)
(Factory Reserved) 80.0
Pr3-19 AVO Analog output bias -10.00〜10.00V 0.00
Pr3-20 (Factory Reserved) (Factory Reserved) 4.00
Pr3-21
User defined analog output
value
0.0〜100.0% 0.0
Group 4: Multi-Step Speed and Process Logic Control operation parameters
Parame
ters
Functions Settings
Factory
Setting
User
Pr4-00
The 1st step speed of PLC Run
or MSS Run
0.00〜600.00 Hz
0.00
Pr4-01
The 2nd step speed of PLC Run
or MSS Run
0.00〜600.00 Hz
0.00
Pr4-02
The 3rd step speed of PLC Run
or MSS Run
0.00〜600.00 Hz
0.00
