2 product introduction
2.1
introduction
F10A optical zoom pod adopts 10 times optical zoom lens, 1 / 2.8cmos sensor,
1080p resolution, equipped with high-precision 2-axis platform, with a total weight
of 300g. F10A pod adopts micro HDMI video output interface, supporting SBUS,
serial port and can bus control. It is especially suitable for fixed wing UAV, rotor UAV,
unmanned helicopter, unmanned vehicle, unmanned ship, patrol robot and other
intelligent equipment in the field of patrol inspection, investigation, monitoring,
etc.
Port description
12P PORT
：
1-12
：
5V+
、
SBUS
、
SBUS ground
、
CAN H
、
CAN L
、
TX
、
RX
、
ground
、
VCC-
、
VCC-
、
VCC+
、
VCC+
USB1
：
Pod SD card reading interface, please connect pod power supply when using
USB2
：
Upgrade the pod firmware, set the interface, and disconnect the pod power supply
when using
