COMMON COMPONENTS
EP500
Common components
used in pumps
EP500 Torque Wrench
Power Pump
NOTES :
PENDANT DECAL KIT (+ + = COMPONENTS) -- PART # 54489
REBUILD KIT ( * = COMPONENTS) -- PART # 54487
ITEM # DESCRIPTION 115 V. 230 V. QTY. ITEM # DESCRIPTION 115 V. 230 V. QTY.
02 PUMP ASSEMBLY 1.00 30 BHCS 10-24 x 3/8 LG 69236 69236 4.00
03 RESERVOIR BLACK 1.00 30 BHCS 10-24 x 3/8 LG 69236 69236 4.00
04 RESERVOIR GASKET 1.00 35 DECAL 5.71" x 1.15" 46355 46355 2.00
05 BREATHER VENT 3/8" NPT 46348 46348 1.00 39 BRACKET SUPPORT G3 46338 46338 1.00
06 PIPE PLUG 1/4" W/ COATING 46510 46510 1.00 42 HOLE PLUG 1/4" 46405 46405 4.00
07 SAE #12 HEX PLUG WITH PORT 46118 46118 1.00 43 SPACER 1.5" LONG 46010 46010 2.00
08 HHCS
1/4-20 X .75 PLT 65891 65891 14.00 44 HHCS 1/4-20 X 2.00 40970 40970 2.00
09 SEALING WASHER 65892 65892 14.00 45 WASHER 1/4" SS 88429 88429 2.00
10 G3 RESERVOIR DECAL 46016 46016 2.00 46 COIL WITH DIN CONNECTOR 46294 46324 1.00
11 LABEL SAFE USE ELEC 68068 68068 1.00 52 SIGHT GAUGE 46009 46009 1.00
12 BLANK DECAL 3 X 4 87305 87305 1.00
13 MANIFOLD ASM. 1.00
14 VALVE GASKET 69242 69242 1.00
15 SHCS 3/8-16 X 2 3/4 99921 99921 3.00 57 1/4 IN NIPPLE 4100067 4100067 1.00
16 ADAPTER ASSY. 68963 68963 1.00 58 1/4" NIPPLE CT210 CT210 1.00
17 HEX PIPE PLUG 3/8" COATING 46513 46513 1.00 59 1/4" SELF-LOCKING COUPLER 45765 45765 1.00
19 VALVE ASM. 2P/4W 1.00 62 GAUGE SHROUD ASM 46474 46474 1.00
20 SHCS 3/8-16 X 3 1/2 88363 88363 4.00 68 VELCRO STRAP 1x14 46310 46310 1.00
21 LOCK WASHER 3/8 93943 93943 4.00 70 MOTOR GASKET 1.0
0
22 ROLL PIN 1/8 X 3/8 LG 561604 561604 1.00 71 GASKET POW'R PUMP 1.00
24 MAGNET 66021 66021 1.00 73 COVER PLATE 1.00
25 MOTOR SHROUD W/ HANDLE 45534 45534 1.00 74 SHCS #10-24 X 5/8" 86699 86699 1.00
26 HOSE CLAMP 69235 69235 1.00 75 SHCS #10-24 X 1" LG 41327 41327 2.00
27 DECAL OVERLAY 46539 46539 1.00 76 G3 MOTOR 1.5HP 115V 45418 45428 1.00
28 BRACKET ASM G PET 1.00 77 FHCS 10-24 X 0.50LG 43557 43557 1.00
29 HEAVY HEX JAM NUT 1/4-20 69234 69234 2.
00 78 SHCS #10-32 X .875 45084 45084 1.00
84 FOAM INSERT 46352 46352 1.00
*
SEE PAGE 23
*
SEE PAGE 32
SEE PAGE 34-35
SEE PAGE 26
SEE PAGE 23
SEE PAGE 33
*
++
++
++
