TU Series Wrench Technical & Dimensional Data
Model Number TU-2 TU-3 TU-5 TU-7
Square drive 3/4” 1” 1 1/2” 1 1/2”
Min. Torque (ft/lbs) 127 330 550 740
Max. Torque (ft/lbs) 1270 3330 5500 7400
Min. Torque (nm) 172 447 745 1003
Max. Torque (nm) 1722 4514 7457 10031
Output Accuracy +/-3% +/-3% +/-3% +/-3%
Repeatability 100% 100% 100% 100%
Duty Cycle 100% 100% 100% 100%
Tool Weight (lbs/kg) 5.6/2.5 10.9/4.9 18.1/8.2 19.0/8.6
Height (in/mm) 4.20/106.7 5.33/135.3 6.40/162.6 7.17/182.1
Length 1 (in/mm) 4.82/122.4 6.40/162.5 7.91/200.9 8.84/224.5
Length 2 (in/mm) 6.34/161.0 8.43/214.1 10.66/270.7 11.58/294.1
Radius (in/mm) 0.98/24.9 1.31/33.2 1.57/39.8 1.77/44.9
Width 1 (in/mm) 2.00/50.8 2.63/66.8 3.12/79.2 3.61/91.7
Width 2 (in/mm) 2.79/70.9 3.68/93.5 4.64/117.8 5.06/128.5
Width 3 (in/mm) 4.42/112.3 5.81/147.6 7.00/117.8 7.98/202.7
