Part Numbers for Ordering (CYLINDERS)
Part TX-2 TX-4 TX-8 TX-16 TX-32
1
HOUSING TX-2-C01 TX-4-C01 TX-8-C01 TX-16-C01 TX-32-C01
2
PISTON BRASS BUSHING TX-2-C51 TX-4-C51 TX-8-C51 TX-16-C51 TX-32-C51
PISTON ROD ASSEMBLY TX-2-C03 TX-4-C03 TX-8-C03 TX-16-C03 TX-32-C03
3
PISTON ROD TX-2-C03-1 TX-4-C03-1 TX-8-C03-1 TX-16-C03-1 TX-32-C03-1
4
PISTON CAP N/A N/A N/A TX-16-C03-2 TX-32-C03-2
5
VALVE BALL TX-2-C03-3 TX-4-C03-3 TX-8-C03-3 TX-16-C03-3 TX-32-C03-3
6
VALVE SPRING TX-2-C03-4 TX-4-C03-4 TX-8-C03-4 TX-16-C03-4 TX-32-C03-4
7
VALVE HOLLOW LOCK TX-2-C03-5 TX-4-C03-5 TX-8-C03-5 TX-16-C03-5 TX-32-C03-5
9
SLIDER TX-2-C09 TX-4-C09 TX-8-X09 TX-16-C09 TX-32-C09
10
END CAP TX-2-C11 TX-4-C11 TX-8-C11 TX-16-C11 TX-32-C11
11
RETAINING RING TX-2-C13 TX-4-C13 TX-8-C13 N/A N/A
12
LINK PIN TX-2-C15 TX-4-C15 TX-8-C15 TX-16-C15 TX-32-C15
13
END COVER TX-2-C17 TX-4-C17 N/A N/A N/A
14
END COVER SCREWS TX-2-C23 TX-4-C23 N/A N/A N/A
15
BALL PLUNGER TX-2-C25 TX-4-C25 TX-8-C25 TX-16-C25 TX-32-C25
16
SLIDER PIN TX-2-C27 TX-4-C27 TX-8-C27 TX-16-C27 TX-32-C27
17
END PLUG SEAL TX-2-C29 TX-4-C29 TX-8-C29 TX-16-C29 TX-32-C29
18
ROD SEAL TX-2-C31 TX-4-C31 TX-8-C31 TX-16-C31 TX-32-C31
19
PISTON O-RING TX-2-C33 TX-4-C33 TX-8-C33 TX-16-C33 TX-32-C33
20
SWIVEL (2 Required) STX-4M-8M STX-4M-4M STX-4M-4M STX-4M-4M STX-4M-4M
21
COUPLER ASSEMBLY HC-S-100 HC-S-100 HC-S-100 HC-S-100 HC-S-100
22
SEAL INSERTION TOOL ATX-2-ST ATX-4-ST ATX-8-ST N/A N/A
23
END PLUG WRENCH N/A N/A N/A ATX-16-EPW ATX-32-EPW
11/20
