TorcUP TX-2 - Torque Conversion Data; Hydraulic Pressure to Torque Conversion Charts

TX Series Torque Conversion Chart
Bar/N.M.
TX-2 TX-4 TX-8 TX-16 TX-32
Hex
3/4" to 1-13/16" 1-7/8" to 2-3/8" All Hex Sizes All Hex Sizes 2-5/8" to 3-15/16" 4" to 4-5/8" 2-7/16" to 4-5/8" 4-11/16" to 6-1/2"
Sizes
19 to 46MM 47 to 60MM All Hex Sizes All Hex Sizes 65 to 100MM 105 to 115MM 80 to 115MM 115 to 155MM
Bar
N.m. N.m. N.m. N.m. N.m. N.m. N.m. N.m.
68
260 285 535 1,125 2,115 2,250 4,324 5,016
82
312 342 644 1,357 2,535 2,700 5,260 6,019
95
365 399 752 1,590 2,955 3,150 6,195 7,022
109
416 455 854 1,822 3,382 3,600 7,130 8,025
122
469 512 962 2,055 3,802 4,051 8,066 9,028
136
522 569 1,071 2,288 4,229 4,501 8,996 10,031
150
572 626 1,179 2,528 4,650 4,951 9,871 11,035
163
625 683 1,288 2,768 5,070 5,401 10,747 12,038
177
678 740 1,389 3,008 5,490 5,851 11,623 13,041
190
728 797 1,498 3,248 5,917 6,301 12,499 14,044
204
784 868 1,606 3,489 6,337 6,751 13,374 15,047
218
832 923 1,715 3,762 6,764 4,826 14,250 16,050
231
885 981 1,823 4,034 7,185 7,651 15,126 17,053
245
937 1,038 1,925 4,307 7,605 8,101 16,002 18,057
258
990 1,097 2,033 4,579 8,032 8,551 16,877 19,060
272
1,045 1,159 2,142 4,853 8,452 9,015 17,895 20,063
286
1,093 1,212 2,250 5,063 8,879 9,466 18,790 21,066
299
1,145 1,270 2,359 5,275 9,299 9,916 19,685 22,069
313
1,197 1,328 2,460 5,485 9,720 10,368 20,579 23,072
326
1,250 1,385 2,569 5,696 10,147 10,818 21,474 24,075
340
1,307 1,450 2,677 5,908 10,567 11,333 22,367 25,079
354
1,353 1,507 2,786 6,152 10,987 11,786 23,266 26,082
367
1,406 1,566 2,894 6,396 11,414 12,240 24,165 27,085
381
1,457 1,624 2,996 6,640 11,834 12,692 25,064 28,088
394
1,510 1,682 3,104 6,884 12,261 13,147 25,962 29,091
408
1,567 1,742 3,213 7,128 12,682 13,692 26,861 30,094
422
1,613 1,799 3,321 7,334 13,102 14,148 27,719 31,097
435
1,666 1,857 3,430 7,540 13,522 14,604 28,577 32,101
449
1,718 1,914 3,531 7,747 13,949 15,061 29,435 33,104
462
1,769 1,972 3,640 7,953 14,369 15,518 30,460 34,107
476
1,829 2,033 3,748 8,161 14,796 15,888 31,153 35,110
490
1,873 2,089 3,857 8,386 15,217 16,342 32,044 36,113
503
1,926 2,146 3,965 8,611 15,637 16,796 32,934 37,116
517
1,979 2,204 4,067 8,837 16,064 17,250 33,825 38,119
530
2,029 2,262 4,175 9,062 16,484 17,630 34,716 39,123
544
2,090 2,325 4,284 9,289 16,911 18,314 35,605 40,126
558
2,134 2,379 4,392 9,520 17,331 18,772 36,495 41,129
571
2,187 2,437 4,501 9,754 17,752 19,231 37,386 42,132
585
2,238 2,494 4,602 9,985 18,172 19,687 38,277 43,135
598
2,291 2,553 4,711 10,219 18,599 20,146 39,167 44,138
612
2,352 2,615 4,819 10,452 19,019 20,361 40,058 45,141
626
2,394 2,669 4,928 10,701 19,446 20,814 40,947 46,145
639
2,447 2,726 5,029 10,951 19,866 21,267 41,837 47,148
653
2,498 2,784 5,138 11,200 20,287 21,718 42,726 48,151
666
2,551 2,843 5,246 11,449 20,714 22,171 43,615 49,154
680
2,614 2,908 5,355 11,699 21,141 22,503 44,504 50,157
5/20
