TX-45 Torque Conversion Chart
P.S.I./FT./lbs
TX-45
Hex
2 7/16” to 4 5/8” 4 11/16” to 6 ½”
Sizes
80mm to 115mm 115mm to 155mm
P.S.I.
ft./lbs. ft./lbs.
1,000
4,685 4,852
1,200
5,415 5,779
1,400
6,145 6,706
1,600
6,875 7,633
1,800
7,605 8,560
2,000
8,338 9,485
2,200
9,180 10,440
2,400
10,022 11,395
2,600
10,864 12,350
2,800
11,706 13,305
3,000
12,548 14,260
3,200
13,422 15,202
3,400
14,296 16,144
3,600
15,170 17,086
3,800
16,044 18,028
4,000
16,921 18,970
4,200
17,762 19,914
4,400
18,603 20,858
4,600
19,444 21,802
4,800
20,285 22,746
5,000
21,130 23,690
5,200
21,978 24,637
5,400
22,826 25,584
5,600
23,674 26,531
5,800
24,522 27,478
6,000
25,372 28,425
6,200
26,192 29,378
6,400
27,012 30,331
6,600
27,832 31,284
6,800
28,652 32,237
7,000
29,475 33,190
7,200
30,328 34,143
7,400
31,181 35,096
7,600
32,034 36,049
7,800
32,887 37,002
8,000
33,740 37,955
8,200
34,562 38,877
8,400
35,382 39,799
8,600
36,202 40,721
8,800
37,022 41,643
9,000
37,840 42,565
9,200
38,706 43,528
9,400
39,572 44,491
9,600
40,438 45,454
9,800
41,304 46,417
10,000
42,170 47,380
TX-45 Torque Conversion Chart
Bar/N.M.
TX-45
Hex
2 7/16” to 4 5/8” 4 11/16” to 6 ½”
Sizes
80mm to 115mm 115mm to 155mm
P.S.I.
N.M. N.M.
68
6,351 6,577
82
7,341 7,834
95
8,330 9,091
109
9,320 10,347
122
10,309 11,604
136
11,303 12,858
150
12,444 14,152
163
13,586 15,447
177
14,727 16,742
190
15,869 18,036
204
17,010 19,331
218
18,195 20,608
231
19,380 21,885
245
20,564 23,162
258
21,749 24,439
272
22,938 25,716
286
24,078 26,995
299
25,218 28,275
313
26,358 29,555
326
27,498 30,834
340
28,644 32,114
354
29,793 33,398
367
30,943 34,682
381
32,092 35,965
394
33,242 37,249
408
34,394 38,533
422
35,506 39,825
435
36,617 41,117
449
37,729 42,409
462
38,841 43,700
476
39,956 44,992
490
41,113 46,284
503
42,269 47,576
517
43,425 48,868
530
44,582 50,160
544
45,738 51,452
558
46,852 52,702
571
47,964 53,952
585
49,075 55,201
598
50,187 56,451
612
51,296 57,701
626
52,470 59,007
639
53,644 60,312
653
54,818 61,617
666
55,992 62,923
680
57,166 64,228
