TorcUP VOLTA 3000 - Technical Specifications

11
TECHNICAL SPECIFICATIONS
Charger Requirements: 110 - 120 V (50-60 Hz) and 230 - 240 V (50-60 Hz)
MODEL NUMBER
VOLTA
500
VOLTA
1000
VOLTA
2000
VOLTA
3000
Square Drive 3/4” 1” 1” 1”
Min. Torque (ft/lbs) 120 240 500 750
Max. Torque (ft/lbs) 500 1000 2000 3000
Min. Torque (Nm) 165 335 700 1025
Max. Torque (Nm) 660 1355 2700 4025
HEIGHT A (w/ battery) (in) 10.40” 10.40” 10.40” 10.40”
HEIGHT A (w/ battery) (mm) 265 265 265 265
LENGTH C (in) 8.86” 10.97” 11.45” 13.94”
LENGTH C (mm) 225 279 291 355
DIAMETER D (in) 2.56” 2.85” 3.09” 3.75”
DIAMETER D (mm) 65 72.4 78.5 95.3
WEIGHT (w/o reaction arm & battery) (lbs) 8.3 11.5 13.1 19.6
WEIGHT (w/o reaction arm & battery) (kg) 3.8 5.2 5.9 8.9
WEIGHT (w/ reaction arm & battery) (lbs) 10.4 14.5 15.9 22.5
WEIGHT (w/ arm & battery) (kg) 4.7 6.6 7.2 10.2
RPM at Min. Torque 12 2 1 0.5
RPM at Max Torque 20 8 5 2
