13
ITEM DESCRIPTION PART # QT Y.
1 VOLTA HANDLE VT-DRIVE HANDLE 1
2 BHCS VT-ADPTR-8 4
3 RETAINING RING VT-ADPTR-9 1
4 RETAINING PLATE VT-ADPTR-42 1
5 RING GEAR VT-ADPTR-32 1
6 PLANETARY GEARS VT-ADPTR-52 3
7 GEAR CARRIER VT-ADPTR-22 1
8 NYLON WASHER VT-ADPTR-11 1
9 GEARBOX ADAPTER VT-ADPTR-6 1
10 BALL RETAINER VT-ADPTR-13 1
11 HOUSING SCREWS VT-ADPTR-14 4
12 STEEL BALL RP-CM-BB 35
VT-1000 Series Wrench with 1” Drive
ITEM DESCRIPTION PART # QT Y.
13 1ST STAGE SPUR GEAR RP-10-ST1-G 3
14 1ST STAGE GEAR CAGE RP-10-ST1 1
15 2ND STAGE SPUR GEAR RP-10-ST2-G 3
16 2ND STAGE GEAR CAGE RP-10-ST2 1
17 HIGH SPEED ANNULUS RP-10-HSA 1
18 THRUST WASHER RP-10-TW 1
19 3RD STAGE GEAR CAGE ASSEMBLY RP-10-ST3A 1
20 DRIVE STAGE ASSEMBLY RP-10-DSTA-1 1
21 MAIN BEARING RP-10-MB-1 1
22 MAIN ANNULUS O-RING DRIVE RP-CM-OR-MA 1
23 DRIVE ANNULUS O-RING RP-10-OR-DA-1 1
24 DRIVE ANNULUS SET SCREW RP-CM-SS-DA 4
25 DRIVE ANNULUS RP-10-DA-1 1
