17
REF# PART # DESCRIPTION QTY
1 Nut M10 5
2 Frame 1
3 Connector assembly 1
4 TRK8041-1 Pin Ø10x40mm 2
5 GB896-8 Side-mount external retaining ring Ø8mm 2
6 TRK8041.1 Hook assembly 2
7 Axle sleeve Ø13x1.5x70mm 3
8 Base assembly 1
9 Fixed sheet metal 1
10 Retaining metal wire 1
11 Positioning palt assembly 1
12 TRK8041-2 Torsion spring 1
13 Hex head screw M10x95mm 3
14 Hex head screw M8x25mm 1
15 GB6170-M10X30 Hex head screw M10x25mm 1
16 Ratchet block assembly 1
17 TRK8041-3 Return spring 1
18 Axle sleeve Ø13x1.5x60mm 1
19 TRK8041-4 Handle grip 1
20 Handle assembly 1
21 GB867-6X10 Rivet Ø6x10mm 1
22 Hex head screw M10x85mm 1
23 GB896-10 Side-mount external retaining ring Ø10mm 2
24 TRK8041-5 Roller 1
25 TRK8041.2 Roller housing 1
26 TRK8041-6 Pin Ø10x30mm 2
27 TRK8041.3 Cable with hook assembly and Capstan 1
28 Link connection for hook 1
29 Guide 1
30 Nut M8 1
