7
98606 (115v) & 90607 (230v) Main Parts List
Item # Description Part #
1 Nut 17883
1 Lock washer 1713
3 Washer 1575
7 Screw 3261
10 Motor cover 17885
11 Catch 18573
12 Spacer 17889
13 Insulation disc 2922
14 Insulation strip 2923
15 Baffle plate 17886
16 Nut 2958
17 Rivet 04972
20 Bumper 10672
21 Switch 16035
22 Ground lead 6354
23 Mounting plate 17888
24 Motor gasket 02941
25 Mounting plate 17897
26 Ring 10689
27 Jam nut 10694
28 Screw 2376
29 Lower cover S/A 17898
30 Washer 3658
32 Screw 10787
33 Connector 6824
34 Silencer 10695
36 Acorn nut 685
37 Strain relief bushing 14552
38 Adapter clip 2962
39 Supply cable (115v) 14411
64 HEPA filter 90608
65 Adapter 16492
66 Screw 64
68 Tank only 14092
72 Caster 10669
76 Tank intake 2914
77 Gasket 2915
78 Intake deflector 14433
79 Intake lock sub-assy 8080
81 Handle – vac head 17890
82 Nut 3868
85 Lockwasher 1246
86 Screw 14991
87 Spacer 6182
88 Screw 1734
91 Nameplate 30812
94 Terminal 611
95 Nameplate 30816
100 Washer 3321
101 Nut ¼-20 x 1” 13910
102 Screw ¼-20 x 3-1/2” 13909
103 Bumper 11942
104 Screw 2038
106 Nut 16129
107 Decal - warning 17881
108 Switch guard 17880
109 Lockwasher 14259
110 Screw 17884
111 Lead 17893
112 Carrier band 13905
113 Bumper band 13906
** Motor Wiring Terminal 15139
** Motor assy (115v only) 14800
** Carbon brushes 23384
** Carrier Assembly 13911
** Decal – hazmat caution 14449
** Line filter (230v only) 31067
** Power cord (230v only) 31059
** Motor assy (230v only) 17425
** Not illustrated
