Tornado CV 30/1 User Manual

– 5
Technical specifications
CV 30/1 CV 38/1
Mains voltage V 120 120
Frequency Hz 1~ 60 1~ 60
Rated current A 9 9
Air volume (max.) CFM (l/s) 102 (48) 102 (48)
Negative pressure (max.) mm (kPa) 2140 (21.0) 2140 (21.0)
Protective class II II
Length x width x height in (mm) 48.0 x 12.0 x 12.5
(1220 x 310 x 320)
48.0 x 15.5 x 12.5
(1220 x 390 x 320)
Width of the brush roller in (mm) 12.0 (300) 15.0 (380)
Typical operating weight lbs (kg) 19.6 (8.9) 20.3 (9.2)
Max. ambient temperature °F (°C) 104 (+40) 104 (+40)
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 67 67
Uncertainty K
pA
dB(A) 1 1
Power cord SJT 3x18 AWG
Part no.: Cable length
Tornado 4.649-026.0 39.5 ft (12 m)
12 EN

Tornado CV 30/1 Specifications

General

Brand	Tornado
Model	CV 30/1
Category	Vacuum Cleaner
Language	English
