9
6. Drive two screws provided ( M4 ) into two upper holes in the bracket, leaving a
gap of 5mm between the screw head and the bracket (Fig. 7)
7. Hang on wall the unit align its two key holes at two screws in bracket .(Fig.8)
8. Drive two screws provided ( M4 ) through the low two holes of the base into the
bracket and secured the unit firmly against the bracket.(Fig.8)
9. Tighten the two upper screws through the base upper hole also.(Fig.8)
CLEANING / MAINTENANCE INSTRUCTIONS
ATTENTION
FAN BLADE & FRONT GRILL CLEANING
User Servicing Instructions
Follow these instructions to correctly and safely care for your unit..
1. Always unplug the fan before cleaning or disassembling.
2. Do not allow water to drop on or enter into fan housing.
3. Be sure to use a soft cloth moistened with a mild soap solution.
4. Do not use any of the following as a cleaner. Gasoline, thinner, Or benzene.
1. Remove the screw and nut at the bottom of front grill,
2. Turn open all buckles at the rim of the grill and remove the front grill.
3. Clean the fan blade and grill with a soft damp cloth. DO NOT ATTEMPT TO
REMOVE THE FAN BLADE. Do not allow the motor or other electrical
components to be exposed to water.
4. Replace front grill and secure with the screw and nut removed in the first step.
5. Turn all buckles back to the rim.
Grasp plug and remove from the receptacle or other outlet device. Do not unplug
by pulling on cord.
Open fuse cover. Slide open fuse access cover on top of attachment plug
towards blades.
Turn fuse holder over to remove fuse. Remove fuse carefully.
Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse(provided with product).
Close fuse cover. Slide closed the fuse access cover on top of attachment plug.
Risk of fire. Do not replace attachment plug. Contains a safety device (fuse) that
should not be removed. Discard product if the attachment plug is damaged.
