Tornado PS Series 98220

16
ES SERIES CARPET SPOTTERS
64230, 98220 & 98221
MAIN ASSEMBLY
(REF. DWG. 98221)
ITEM NO. DESCRIPTION PART NO. QTY.
1 SCREW-SLOTTED ROUND HEAD MACHINE #8-32 x ¾ 00600 2
2 WASHER-LOCK (H/S) #10 01713 1
3 NUT-HEX LOCK (KEPS) #8-32 02956 2
4 SCREW-PHILLIPS PAN HD. MACH. # 8-32 X 3/8" 02995 4
5 WASHER – SEALING ¼ 07741 2
6 NUT-HEX.LOCK(KEPS) #10-24 10892 6
7 WASHER-PLAIN 1/2" 12957 1
12
MOTOR-VACUUM,115V/50-60HZ (98220 & 64230 ONLY)
14800 1
(12)
MOTOR-VACUUM,230V/50-60HZ (98221 ONLY)
17425 1
8 FITTING-BRASS NIPPLE 1/4"FPT X 1/4"Q.C. 14881 1
9 CLAMP-HOSE(CRIMP TYPE) .433"-.512"(2-EAR) 15065 4
10 FITTING-BRASS ELBOW(45D) 1/4"FPT X 1/4"MPT 15075 2
11 FITTING-BRASS ELBOW 1/4"MPT X 3/8"HB 15223 1
13 SCREW - PHILLIPS TRUSS HD. MACH. #10-24 X 1/2" (SS) 17848 11
14 WASHER-PLAIN #10 (SS) 17850 8
15 WASHER-PLAIN 5/16" (SS) 19191 4
16 SCREW-PHILLIPS FLAT HD. MACH. # 8-32 X 1/2" (BLK.ZINC) 19255 2
17
TANK-SOLUTION (98220 & 98221 ONLY)
19490 1
(17)
TANK-SOLUTION (64230 ONLY)
30896 1
18
TANK-RECOVERY (98220 & 98221 ONLY)
19491 1
(18)
TANK-RECOVERY (64230 ONLY)
30897 1
49
PUMP- 55 PSI/115VAC - (64230 & 98220 ONLY)
31479 1
(49)
PUMP- 55 PSI/230VAC - (98221 ONLY)
31480 1
19 LATCH-DRAW W/ KEEPER 19504 2
20 WHEEL- 6" DIA. X 1-1/4" (BLACK W/ BLK HUB) 19505 2
21 SPACER-5/16" DIA. 19506 2
22 NUT-HEX.LOCK (NYL.INS.) 5/16-18 19513 2
23 ASSEMBLY-VACUUM STACK/FLOAT CAGE 19516 1
24 SCREEN-VAC.MOTOR INTAKE 19517 1
25 FILTER-VAC.MOTOR INTAKE (FOAM) 19520 1
26 PIPE-NIPPLE, PVC 1/4"MPT X 4" LG. 19522 1
27 FITTING-BRASS ADAPTOR 1/4"FPT X 1/4" HB 19523 2
28 FITTING-NYLON ELBOW 1/8"MPT X 1/4"HB 19524 2
29 FILTER-SOL. SCREEN 19525 1
30 HOSE-SOLUTION (SCREEN) 19528 1
31 WASHER-LOCK (I/T) # 8 19530 4
32 SCREW-PHILLIPS PAN HD. MACH. 5/16-18 X 2-1/2" (SS) 19532 2
33 LABEL-"WARNING!TO REDUCE THE RISK OF ELECTRIC..." 19533 1
50 BRACKET-PUMP MTG(RUBBER) 31490 2
34 SCREW-PAN HEAD #10-16 X 1/2" LG. 19565 4
35 GASKET-SOLUTION TANK 19610 1
36 LABEL-"VACUUM ONLY-OFF-VACUUM/SPRAY"SWITCH(PS) 19611 1
37 WASHER-PLAIN 1/2" (SS) 19616 3
38 SHROUD, VAC MOTOR 19937 1
39 WASHER - LOCK E/T #10 30019 6
40 GASKET-VAC. MOTOR BOTTOM 30456 1
41 GASKET, MOTOR TOP 30457 1
42 SWITCH-ROCKER, DPDT (3 POS.) 15A 30472 1
43 BRACKET-VAC. MOTOR MT'G 30475 2
48 BRACKET-PUMP MT'G 31471 1
44 SCREW-PHILLIPS PAN HEAD MACHINE # I0-24 x 3/8 30678 10
45 DECAL-"TORNADO" 30814 1
47
LINE FILTER 31067 1
51
HOSE-SOLUTION (PUMP) 19527 2
46
ASS'Y POWER CORD 115V (64230 & 98220 ONLY)
19499 1
(46)
ASS'Y POWER CORD 230V (98221 ONLY)
31059 1
* = NOT SHOWN
( ) = ITEMS TO BE USED WHERE APPLICABLE
