Tornado PS Series 98220

20
ES SERIES PORTABLE CARPET SPOTTERS
64230, 98220
CIRCUIT ASSEMBLY (REF. DWG. 98220A)
ITEM NO. DESCRIPTION PART NO. QTY.
1 WASHER-LOCK (H/S) #10 01713 1
2 SCREW-TCT (F) PAN HEAD #10-32 X 3/8" 03261 1
3 TERMINAL-CLOSED END CRIMP(INS) 06824 1
*4 STRAIN RELIEF(LIQ.TITE) .35 DIA. CORD 18793 1
5 LEAD-14 GA. X 3" BLACK 19466 2
6 ASSEMBLY-POWER CORD,115V (SPOTTER)
(INCLUDES ITEM 4)
19499 1
7 ASSEMBLY-POWER CORD,230V (SPOTTER) 19500 1
8 TERMINAL-Q.D.FEMALE 1/4" X 22/18GA. (FUL.INS) 19503 1
9 LEAD-18 GA. X 12"GREEN 19536 1
10 LEAD-16 GA. X 12"BLACK 19537 1
11 LEAD-16 GA. X 12"WHITE 19538 1
OPTIONS AND ACCESSORIES
ITEM NO. DESCRIPTION PART NO. QTY.
* TOOL-UTILITY DETAILER (DELUXE) 3-1/2"
SPRAY/VAC.
98341 1
* TOOL-CREVICE DETAILER SPRAY/VAC. 98342 1
* TOOL-UPHOSTERY/CURTAIN (PERFORATED)
4"SPRAY/VAC.
98343 1
* TOOL-UTILITY/STAIR 6" SPRAY/VAC. 98344 1
* = NOT SHOWN
